CKJPF86,CKJP86,CKJPFP-20*1.5船用控制电缆
额定电压: 根据型号
产品颜色: 黑色
护套材料: 根据选型
产品型号: 客户选型
屏蔽材质: P镀锡铜丝屏蔽
产品包装: 盘装或软包
文章标签:暂无
产品详情
产品名称: |
船用控制电缆 |
产品型号: |
CKXV、CKEF、CKJV、CKEPJ等 |
产品特点: |
本品适用于交流额定电压250V及以下的各种船舶及海上石油平台等水上建筑物,用于对干扰不敏感电路。用于各种船舶及海上石油平台等控制系统。 |
一:产品用途:产品用于河海各种船舶及海上石油平台等水上建筑一般控制装置用。
Scope of applications:The product uses in river sea each kind of ships and the marine petroleum platform and so on the aquatic building general control device use
二:执行标准:IEC60092-376或GB9332-88
Standards implemented:IEC60092-376 or GB9332-88
三:型号规格、燃烧特性及额定电压
Models specifications、Combustion and Rated voltage
型号Models |
燃烧特性 Combustion |
芯数 Core number |
标称截面(mm2) Nominal sectional area |
额定电压(KV) Rated Voltage |
温度 Temp.℃ |
CKEF(HV)、CKEF(HV)80、CKEF(HV)90 CKEF(HV)82、CKEF(HV)92 |
DA
SA NA |
2-37 |
0.75-1 |
0.25 |
E:85 J:85 V:70 |
CKVV、CKVV80、CKVV90、CKVV82、CKVV92 | |||||
CKJV、CKJV80、CKJV90、CKJV82、CKJV92、CKJP82、 CKJVP、CKJVP80、CKJVP90、CKJVP82、CKJVP92 | |||||
CKEPJ、CKEPJ80、CKEPJ90、CKEPJ85、CKEPJ95、CKEPF CKEPF80、CKEPF90、CKEPF86、CKEPF96、CKJPF CKJPF80(90)、CKJPF86(96)、CKJP86、CKJPFP、CKJPFP80(90) CKJPFP86(96)、CKJ85、CKJ86、CKJPJ、CKJPJ80(90) CKJPJ85(95)、CKJP85、CKJPJP、CKJPJP80(90)、CKJPJP85(95) |
SC
NSC |
0.5-2.5 |
85 |
四:产品名称及代号 Product descriptions and Code
代号 Codes |
定义 Definition |
代号 Codes |
定义 Definition |
D |
单根燃烧 Combustion for single cable |
A |
有烟有酸有毒 have smoke acidity and toxicity |
S |
成束燃烧 Combustion for bunched cable |
B |
低烟低酸低毒 low smokelow aciditylow toxicity |
N |
耐火(单根燃烧) Fire-proof(Combustion for single cable) |
C |
无卤低烟低毒 Halogen freelow smokelow toxicity |
